High Precision Magnetic Scale Encoder - Digital Readout Non-Contact Measurement for Industrial Automation | CNC Machines, Robotics & Motion Control Systems

Product Description

Feature:1. The product possess high system accuracy, high repeatability, and 5 micron high resolution2. Come with a intelligent error indicator which showing the working status of the encoder3. Encoder reading head provides industry standard digital signal of A+, A‑, B+, B‑, Z+, Z‑4. High‑quality braided shielded connecting wire can resistant to bending, abrasion and interference5. Non‑contact measurement, resistant to dust, impact, vibration, and magnetic field interference6. Possess high degree of protection, resistant to oil, dust, lubricants and other pollutionSpec:Item Type: Magnetic Scale Encoder Reading HeadPower Supply Voltage: 5V or 7-28V +/-5% (optional)Magnetic Distance: Approx. 5mm / 0.2in or approx. 2mm / 0.08in(optional)Resolution: Magnetic Distance 5mm: 0.0025--0.625mm, Magnetic Distance 2mm: 0.001-0.25mmSystem Accuracy: ±(0.025+0.02 x L) mmOutput Frequency: 100KHzCurrent: 20MΩWithstand Voltage: 500VAC (50/60Hz, time 1 minute, between terminal and shell)Protection Level: IP67Package List:1 x Magnetic Scale Encoder Reading Head1 Pack of Screw Accessories1 x User ManualNote:If the customer does not require, unified 5V, 5mm, 4‑core shielded wire, with direct wire out, RS422 delivery.
